Smart City and Energy

Skyworks is an industry leader in semiconductors and has years of experience servicing IoT industry. With years of experience and in-house manufacturing capability, we are enabling breakthrough communication platforms from global industry leaders – changing the way we live, work and play. Through our broad technology expertise and one of the most extensive product portfolios in the industry, we are Connecting Everyone and Everything, All the Time.

Connecting Everyone and Everything, All the Time.

White Paper

White Paper: Skyworks FEMs for Smart Utility Metering and IoT

Learn more

FEMs for Smart Utility Metering and IoT

Part Number	PA	LNA	Ant1, Ant2	Package (mm x mm)	Frequency (MHz)	Tx Pout (dBm)	Tx Gain (dB), Icc (mA) @Pout (dBm)	Tx bypass loss (dB)	LNA gain/NF(dB), Icc (mA)	Rx bypass loss (dB)	Sleep Icc (μA)	Mode switching time (μs)	VDD/VCC (volts)
RFX1010	✓	✓	Ant 1	3 x 3	780-960	27	28, 350@27	NA	14/3, 16 12/3.5, 10	NA	1	1	2.7-3.6
SE2435L-R	✓	✓	Ant 1 Ant 2	4 x 4	860-930	30	26, 550@30 26, 275@24	NA	16/2, 6	2	< 1	< 1	2.0-4.8
SKY65111-348LF	✓		RF OUT	3 x 3	600-1100	33	36, 700@29.5	NA	NA	NA	< 10	NA	2.5-5.0
SKY65362-11	✓	✓	Ant 1 Ant	2	6 x 6	900-930	30.5 33, 515@30.5	NA	16/2.5, 6	3	0.05	< 11	3.0-5.25
SKY65364-11	✓	✓	Ant 1	6 x 6	890-960	30.5	21.9, 730@30	NA	16/1.7, 20	0.9/3	0.03	0.5	Tx: 3.4-3.8 Rx: 3.0-3.45
SKY65364-21	✓	✓	Ant 1	6 x 6	890-960	30	16, 680@30	NA	15/1.5, 12	0.5/3	0.50	0.5	Tx: 3.4-3.8 Rx: 3.0-3.45
SKY66101-11	✓	✓	Ant 1 Ant 2	6 x 6	902-928	30	33, 670@30	NA	16/2.5, 6	3	< 1	< 1	2.0-4.8
SKY66105-11	✓		Ant 1 Ant 2	6 x 8	902-931	30	29, 450@29	NA	NA	0.7	< 10	1-2	2.0-4.8
SKY66122-11	✓	✓	Ant 1	6 x 6	863-928	30	30, 640@30	NA	16/2.5, 6.5	NA	< 1	1-3	3.0-5.0
SKY66420-11	✓	✓	Ant 1	3 x 3	860-930	27	16, 280@27	< 1.5	18/1.5, 5	NA	< 1	Tx: < 2 Rx: < 4	2.0-4.8
SKY66421-11	✓		Ant 1	3 x 3	860-930	27	16, 280@27	NA	NA	0.6	< 1	< 1	2.0-4.8
SKY66422-11	✓	✓	Ant 1	3 x 3	860-930	22	20, 80@20	2.2	17/1.7, 4	NA	0.40	Tx: 20/0.2 Rx: 10/4	2.5-3.6
SKY66423-11	✓	✓	Ant 1	3 x 3	860-930	27	29, 280@27	< 1.5	18/1.5, 5	NA	< 1	Tx: 2 Rx: 4	2.0-4.8
SKY66100-11	✓		Ant 1	4 x 4	169-170	27	32, 325@27	0.9	NA	0.4	< 1	< 1	2.0-3.6
SKY66121-11	✓		Ant 1	4 x 4	169-170	30	39, 600@30	NA	NA	w/ filter 0.9	< 1	1	2.0-4.0
SKY65366-21	✓	✓	Ant 1	6 x 6	400-500	30.2	20, 780@30	2	21/1.8, 12	2	0.30	0.5	Tx: 3.7-4.0 Rx: 3.0-3.45
SKY66119-11	✓	✓	Ant 1	6 x 6	450-470	30.5	25, 740@30	1.8	15.5/1.3, 5	2.3	0.03	0.5	Tx: 3.4-3.8 Rx: 3.0-3.8

(NA indicates Not Applicable)

Resources

White Paper Skyworks FEMs for Smart Utility Metering and IoT Skyworks_Smart_Utility_IoT_whitepaper.pdf
