Si5332A-GM1

Si5332A-GM1 Low Jitter Clock Generator with 6 Outputs and Integer and Fractional Frequency Synthesis Modes

The Si5332A-GM1 any-frequency clock generator provides the highest level of integration available, enabling complete clock tree consolidation in 10/25/40/100G data center communications and industrial applications. With an output frequency range of 5 - 333.33, the device features both MultiSynth fractional as well as integer dividers, high speed integer dividers. jitter performance of 0.190ps TYP, low power consumption and has 6 outputs. The Si5332A-GM1 also includes up to 5 user-defined hardware input pins that can be assigned as output enable for one or more outputs, frequency control, spread spectrum enablement, or input reference selection. Si5332A-GM1 can be quickly and easily configured using ClockBuilder Pro software, offering both factory pre-programmed as well as in-system programming options.

Data Sheets Eval Kit Customize

Support ECAD Model

Specifications

Loop Bandwidth Max (MHz)—

Temperature Range Min (°C)-40

Input Frequency Min (MHz)10

Package TypeQFN32

ControlI2C/Pin

OPNSi5332A-D-GM1

Line Impedance Match0

Clock Generatorstrue

Jitter Attenuating Clocksfalse

Number of Outputs6

Input Frequency Max (MHz)250

Intel x86 Clocksfalse

Package Size (mm)5x5

Real Time Clockfalse

DescriptionAny-Freq Low Jitter Clock Gen

Frequency Reference—

4G/LTE Wireless Clocksfalse

56G SerDesfalse

Ouput Format(s)LVPECL; LVDS; LVCMOS; HCSL

VDDO (V)1.8; 2.5; 3.3

VDD (V)1.8; 2.5; 3.3

Jitter Recommended Range (fs)<

Phase Jitter (ps RMS)0.190

PCI Expresstrue

Spread Spectrumtrue

Synchronous Ethernet/1588false

PLLsNo

DSPLLs0

Reference Inputs2

Xtal Input Frequency—

Output Format CategoriesDifferential; Single-Ended

Standards Compliance—

Output Frequency Min5

Embedded Xtalfalse

Loop Bandwidth Min (MHz)—

Temperature Range Max (°C)85

Output Frequency Max333.33
