Si53352A-01AM

Si53352A-01AM 1:2 Clock Buffer Level/Translat

The Si53352A-01AM is a universal 1 : 2 low jitter clock buffer/level translator. Users can fully customize the input/output format and voltages using ClockBuilder Pro, or choose the fixed-function alternative that features hardware input pins to select the input/output clock format level (LVDS, LVPECL, HCSL, LVCMOS). The Si53352A-01AM utilizes Skyworks' advanced CMOS technology to fanout ten copies of a 10 to 333.33 MHz input reference clock, with guaranteed low additive jitter, low skew and low propagation delay variability. The Si53352A-01AM features minimal cross-talk and provides superior supply noise rejection, simplifying low jitter clock distribution in noisy environments. Independent core and output bank supply pins provide integrated level translation without the need for external circuitry.

Data Sheets Eval Kit Customize

Buy Now Support ECAD Model

Specifications

Temperature Range Min (°C)-40

Package TypeQFN32

OPNSi53352A-D01-AM

Line Impedance Match0

Universal Buffersfalse

Number of Inputs1

Number of Outputs2

Frequency Max250

Frequency Min (MHz)10

Package Size (mm)5x5

Description2-output Clock Buffer Auto Grade

Ouput Format(s)HCSL; LVCMOS; LVDS; LVPECL

VDDO (V)1.8; 2.5; 3.3

Additive Jitter (ps RMS)0.1

VDD (V)1.8; 2.5; 3.3

PCIe Compliantfalse

Feedback Pathfalse

Output Format CategoriesDifferential; Single-Ended

PCIe Performance1; 2; 3; 4; 5

Single Ended Inputfalse

LVCMOS Buffersfalse

Differential Buffersfalse

Temperature Range Max (°C)105

Dualfalse

Zero Delay Buffersfalse
