SKY65728-11

SKY65728-11: Shielded Low-Noise Amplifier Front-End Module with GPS L5 Pre-Filter

The SKY65728-11 is a shielded front-end module (FEM) with an integrated low-noise amplifier (LNA) and pre-filter designed for Global Positioning System (GPS) L5 band receiver applications. The device provides high linearity, excellent gain, a high 1 dB input compression point (IP1dB), and a superior noise figure (NF).

The pre-filter provides the low in-band insertion loss and integrated notch filtering for excellent rejections of the cellular, PCS, and WLAN frequency bands. The SKY65728-11 uses surface-mount technology (SMT) in a Multi-Chip Module (MCM) package, which allows for a highly manufacturable and low-cost solution.

Data Sheets

Buy Now Talk to Sales ECAD Model

Specifications

Product LifecyclePre Release

Frequency (MHz)1164-1189

Test Frequency (MHz)1176

DescriptionShielded Low-Noise Amplifier Front-End Module with GPS L5 Pre-Filter

Gain (dB)16

V_DD (V)1.1-2.85

I_{P1 dB} (dBm)-18

NF (dB)1.6

PackageMCM, 9-pin

Package (mm)1.6 x 1.6 x 0.7

Features

Innovative proprietary shielded technology
Wideband pre-filter
Small signal gain: 16 dB typical
Excellent out-of-band rejection
Low noise figure: 1.6 dB typical
Low current consumption
Input/output impedance internally matched to 50 
Single DC supply: 1.1 to 2.85 V
Minimal number of external components required
Small MCM (9-pin, 1.6 x 1.6 x 0.7 [nominal] mm) package (MSL3, 260 °C per JEDEC J-STD-020)

Product Documents

Applications

Wearables

See all

Smartphones

See all

Tablets

See all
